- (CS01 - 65) -
Control system
- (CS01 - 65) -
CONTROL
SYSTEM
CONTROL
SYSTEM
Domestic Hot Water
LINE FUNCTION
8820 DHW pump
8821 Electric immersion heater DHW
8830 DHW temperature
8840 Hours run DHW pump
8841 Start counter DHW pump
8842 Hours run electric DHW
8843 Start counter electric DHW
The measured values, the DHW circulation
p
ump and charging temperature, operating hour
and start-up counters are displayed, as well as
temperatures of the primary controllers and DHW
heater.
Swimming Pool
LINE FUNCTION
8900 Swimming pool temp
The current temperature of the swimming pool is
d
isplayed.
Line
LINE FUNCTION
8950 Common ow temp
Multifunction Relay Status
LINE FUNCTION
9031 Relay output QX1
9032 Relay output QX2
9033 Relay output QX3
9034 Relay output QX4
9035 Relay output QX5
The switching status of multifunction relays 1 - 5 can
be
viewed individually on these lines. The display
"Off" means that the components assigned to this
output are currently disconnected. The display "On"
means that the associated components are
currently switched on.
