* If the control device does not provide a potential-free contact, the contact must be relayed to create equivalent wiring.
In all cases, please refer to the instruction manuals for the external components (load shedder, power meters) to create
the wiring.
** Option The connection of terminal 3 of the remote control is not mandatory. (lighting of the room control unit)
Regulation of wire size and circuit breaker differs from each locality, please refer in accordance with the regional standard.
