3. PLOTTER OPERATION
3-34
3.8.4 Changing waypoint mark size (FURUNO, NavCharts™)
You may change the size of all waypoint marks to small or large (default), or you
may turn them off.
1. Press the [MENU] key to open the menu.
2. Press the CHART SETUP and CHART DETAILS soft keys.
CHART
DETAILS
EDIT
CNTOUR
LINE
RETURN
LAT/LON GRID GREEN
TEXT INFORMATION ON
WAYPOINTS LARGE
WAYPOINT NAMES ON
CHART BORDER LINES ON
LANDMASS BRT YELLOW
BACKGROUND BLACK
NAVAIDS ON
LIGHT SECTOR INFO ON
OTHER SYMBOLS WHITE
MARK SIZE LARGE
Chart details menu
3. Use the trackball to select WAYPOINTS.
4. Press the EDIT soft key.
5. Use the trackball to select LARGE, SMALL or OFF.
LARGE: Shows mark in actual shape.
SMALL: Displays all waypoints with an “X” regardless of mark shape
selected.
OFF: Turns off all waypoints and their names. Waypoints currently used
in navigation are shown regardless of this setting.
6. Press the ENTER soft key.
7. Press the [MENU] key to close the menu.
