1. OPERATIONAL OVERVIEW
1-18
2. Press function key desired.
Note: Function keys can be individually programmed for the plotter, radar and
sounder displays. For further details see the following:
Radar: paragraph 5.2.3
Plotter: paragraph 5.3.2
Sounder: paragraph 5.9.4
1.10 Simulation Display
The simulation display, for use by service technicians for demonstration
purposes, provides simulated operation to help acquaint you with the many
features your unit has to offer. It allows you to view and control a simulated
plotter, radar and sounder picture, without position-fixing equipment, network
radar or a network sounder. Most controls are operative, thus you may practice
setting destination, enter waypoints, measure range and bearing to a target, etc.
The simulation icon (
S
I
M
) appears when any simulation mode is active.
To start the simulation display;
1. Press the [MENU] key.
2. Press the SYSTEM CONFIGURATION, SYSTEM SETUP and SIMULATION
SETUP soft keys in that order.
SIM
SETUP
EDIT
RETURN
RADAR LIVE
PLOTTER LIVE
SOUNDER LIVE
SPEED 00.0kt
COURSE 000.0
°
LATITUDE 45
°
35.000’N
LONGITUDE 125
°
00.000’W
START DATE & TIME 00:00 01.APR.00
RADAR SIMULATION DATA NO
Simulation setup menu
3. Follow appropriate procedure on the next several pages.
