1. OPERATION
1-27
1.22 Fish Information (ACCU-FISH
™
)
The ACCU-FISH
™
feature measures the length of individual fish and tags the fish with
a fish symbol whose size is proportional to the length of the fish. The length or depth
of the fish can be indicated digitally.
Notice for the ACCU-FISH feature
• This feature requires an appropriate transducer. For the transducer compatible with
this feature, see "EQUIPMENT LISTS" on the installation manual (IME-23860).
• For FCV-1900G, close the fish size histogram window to use the ACCU-FISH
™
.
• The fish length calculated by this fish finder is intended for reference purposes; it is
not a completely accurate measurement of fish length.
• The echo strength of a school of fish changes according to the fish. When the size
shown on the fish size histogram differs from the actual size, adjust [Fish Size] on
the [Calib] menu to compensate for the difference (see page 2-7).
• A fish whose depth is shallower than 2 m can not be measured. Also, the maximum
range depends on the transducer’s performance, installation location, and seastate.
If the [Zero Line Rejection] on the [Calib] menu is turned on, the fish whose depth
is shallower than the transmission line can not be measured.
• With the inside-hull transducer, signal attenuation changes according to the trans-
ducer’s frequency. Therefore, a fish may not be detected or the fish length indicated
may be smaller than actual length.
• In case of a school of fish, echoes overlap one another, so the margin of error will
be greater.
• The TX pulse length changes according to ACCU-FISH
™
On/Off state. This causes
a difference in both sensitivity and the echoes viewed.
Single frequency display
0.00.0
59.859.8
mm
2020
4040
6060
8080
00
0/99
x 1 x 1 x 1
VRM 0.0
Weak reflection
(small fish or noise)
Fish echo
Strong reflection
(bottom)
A-scope display
HF: 2.0
TM
