3. MAINTENANCE & TROUBLESHOOTING
3-5
3.5 Communication Port Monitor
The communication port monitor provides information for the input/output data sen-
tences of the NMEA ports.
1. Press the MENU/ESC key, then open the [Setting] tab.
2. Select [System], then push the ENTER knob.
3. Select [NMEA Port Set&Monitor], then push the ENTER knob.
4. Select the port to display the input/output data, then push the ENTER knob.
5. Press the MENU/ESC key to close the menu window and show the communica-
tion port monitor display.
6. Press the MENU/ESC and select [Exit], then push the ENTER knob.
7. Select [Yes], then push the ENTER knob to close the communication port monitor
display.
8. Press the MENU/ESC key several times to close the menu.
NMEA1
NMEA2
SC
CIF
Shows the information of the CN-10 (NMEA1) port.
Shows the information of the CN-11 (NMEA2) port.
Shows the information of the CN-12 (NMEA3) port.
Shows the information of the CN-6 (SONDE/TRIG) port.
NMEA Port1 Input NMEA Port1 Output
[MENU/ESC] : Setting
Select Exit menu to exit
$GPGNS,102716.01,8900.0413,N,17859.99
99,E,A,00,0.0,0.0,0.0,0.0,0.0,S*4F
$GPMTW,27.30,C*32
$GPVHW,0.00,T359.94,M,8.10,N,,*1C
$GPVTG,359.95,T,359.95,M,6,6.48,N,,,A*7C
$GPZDA,102716.20,24,02,2015,00,00*65
$SDDBT,102.6,f,31.3,M,17.1,F*05
$SDDPT,31.3,0.0,200.0*66
SSDDBT,T102.6,f,31.3,M,17.1,F*05
$SDDPT,31.3,0.0,200.0*66
Input data
Output data
