1. MOUNTING, WIRING

1.1 Preparation

Mounting method

You can install the monitor unit as follows. See the outline drawings at the back of this manual for

mounting dimensions.

• Flush mount, fixed at front (standard)

• Flush mount, fixed at front, with hood (option)

• Flush mount, fixed at rear (option)

• Flush mount, fixed at rear, with hood (option)

• Tabletop mount (option, hood-mountable)

• Flush mount a series side by side, fixed at rear

Note 1: The face of the LCD is made of glass. Handle it with care.

Note 2: For flush mount, take care so that the monitor unit does not fall during the installation.

Mounting location

Select a mounting location considering the following points. This equipment is free from electro-

magnetic fields.

• Make sure the mounting location is strong enough to support the weight of the unit.

• Locate the unit away from direct sunlight. An LCD may darken if it is exposed to direct sunlight

for a long time.

• Select a location where the screen can be easily viewed and the controls can be easily operat-

ed.

• Leave enough space around the unit for service and maintenance. See the outline drawings at

the back of this manual for minimum service clearance.

• Locate the unit away from areas subject to water splash and rain.

• Observe the compass safe distances (see page iii) to prevent interference to a magnetic com-

pass.

Note: If the unit is installed with the screen tilted downwards, the appropriate glass fixing kit (see

“Optional supply” on page vii) must be used.

Run cables before installing the monitor unit

Run all cables before you install the monitor unit. See the interconnection diagram at the back of

this manual.
