Page 4-24 GIA 63/GIA 63W Installation Manual
Revision S 190-00303-05
4.9 DME Tuning and ADF
4.9.1 DME Tuning Function
The GIA 63(W) can channel a DME based on the tuned VLOC frequency. The GIA 63(W) outputs 2 of
5, BCD or Slip parallel DME and King Serial DME channeling format. When DME COMMON is held
low, the GIA 63(W) actively tunes the DME.
4.9.2 DME Interface and ADF Electrical Characteristics
4.9.2.1 Parallel DME Tuning
Pin Name Connector Pin I/O
PARALLEL DME 1 MHZ-D P602 33 Out
PARALLEL DME 100 KHZ-A P602 37 Out
PARALLEL DME 100 KHZ-B P602 39 Out
PARALLEL DME 100 KHZ-C P602 40 Out
PARALLEL DME 100 KHZ-D P602 42 Out
PARALLEL DME 50 KHZ P602 43 Out
PARALLEL DME 1 MHZ-A P602 45 Out
PARALLEL DME 1 MHZ-B P602 46 Out
PARALLEL DME 1 MHZ-C P602 47 Out
PARALLEL DME 100KHZ-E P602 54 Out
PARALLEL DME 1MHZ-E P602 56 Out
NAV DME COMMON P602 41 In
For each of the parallel DME tuning discrete outputs:
INACTIVE: Floating (can be pulled up to externally sourced Vout in the range 0 ≤ Vout ≤ 33VDC)
Leakage current in the INACTIVE state is typically ≤ 10 uA to ground
ACTIVE: Vout ≤ 0.5VDC with ≤ 20 mA sink current
Sink current must be externally limited to 20 mA max
NAV DME COMMON must be pulled low to indicate to the NAV module that it is the device channeling
the DME.
INACTIVE: 10 ≤ Vin ≤ 33VDC or Rin ≥ 100kΩ
ACTIVE: Vin ≤ 1.9VDC with ≥ 75 uA sink current, or Rin ≤ 375Ω
Sink current is internally limited to 200 uA max for a grounded input
