Page 1-2 GTS 8XX/GPA 65 Installation Manual
Revision 4TP 190-00587-00
1.4 Technical Specifications
1.4.1 Environmental Qualification Form
It is the responsibility of the installing agency to obtain the latest revision of the GTS 8XX/GPA
Environmental Qualification Form. This form is available directly from Garmin under the following part
number:
GTS 8XX Environmental Qualification Form, Garmin part number 005-00323-02
GPA 65 PA/LNA Environmental Qualification Form, Garmin part number 005-00323-22
GA 58 Antenna Environmental Qualification Form, Garmin part number 005-00232-23
To obtain a copy of this form, see the dealer/OEM portion of the Garmin web site (www.garmin.com
).
1.4.2 Physical Characteristics
Characteristics Specifications
GTS 8XX Width 2.81 inches (7.14 cm)
GTS 8XX Height 6.94 inches (17.63 cm)
GTS 8XX Depth w/Connector Kit 14.78 inches (37.54 cm)
GPA 65 Width 4.25 inches (10.80 cm)
GPA 65 Height 1.00 inches (2.54 cm)
GPA 65 Depth Not Including
Connector And Cable
7.96 inches (20.22 cm)
GPA 65 Depth w/Connector And
Cable Fully Extended
16.83 inches (42.75 cm)
GTS 8XX Unit Weight w/out
Connector Kit
9.0 lbs. (4.08 kg)
GTS 8XX Unit Weight with
Connector Kit/w Vertical Rack
10.7 lbs. (4.85 kg)
GTS 8XX Unit Weight with
Connector Kit/w Horizontal Rack
11.5 lbs. (5.22 kg)
GPA 65 PA/LNA Unit Weight with
Pigtail Connector Kit*
1.9 lbs. (0.86 kg)
GA 58 TAS/TCAS Antenna
w/screws and o-ring
0.82 lbs. (0.37 kg)
QMA straight connector kit, 4 pcs 0.10 lbs. (0.05 kg)
QMA straight connector kit, 1 pc 0.03 lbs. (0.01 kg)
QMA right angle connector kit,
4 pcs
0.18 lbs. (0.08 kg)
QMA right angle connector kit, 1 pc 0.05 lbs. (0.02 kg)
QMA termination connector kit 0.07 lbs. (0.03 kg)
*Used with the GTS 820 and 850.
