Page 1-4 GTS 8XX/GPA 65 Installation Manual
Revision 4TP 190-00587-00
1.5 Certification
The conditions and tests required for TSO approval of this article are minimum performance standards. It
is the responsibility of those installing this article either on or within a specific type or class of aircraft to
determine that the aircraft installation conditions are within the TSO standards. TSO articles must have
separate approval for installation in an aircraft. The article may be installed only if performed under 14
CFR part 43 or the applicable airworthiness requirements.
The following table provides a list of applicable TSO/ETSOs for the GTS 8XX/GPA 65.
1.5.1 TSO/ETSO Compliance
Applicable
LRU
Function TSO/ETSO Category
Applicable
LRU SW Part
Numbers
Applicable
CLD Part
Numbers
GTS 850
GPA 65
Traffic Alert and Collision
Avoidance System (TCAS I)
Airborne Equipment
TSO-C118
ETSO-C118
006-B0551-()
006-C0081-()**
006-C0092-()***
GTS 800
GTS 820
GPA 65
Traffic Advisory System
(TAS) Airborne Equipment
TSO-C147
ETSO-C147
Class A 006-B0551-()
006-C0081-()**
006-C0092-()***
GTS 800
GTS 820
GTS 850
Extended Squitter Automatic
Dependent Surveillance –
Broadcast (ADS-B) and
Traffic Information Service –
Broadcast (TIS-B)
Equipment Operating on the
Radio Frequency of 1090
Megahertz (MHz)
TSO-C166a
Class
A0/Type 1
Receiving
Only*
Class
A1/Type 1
Receiving
Only*
006-B0551-() 006-C0081-()**
* Equipment is Class A0 when installed with a single antenna, Class A1 when installed with diversity
antennas.
**GTS 8XX only
***GPA 65 only
