GE CS5500 User Manual

8. Repeat these steps to set other languages.
5.5 Setting up a communicator
The CSx75 supports different modes of reporting events to multiple central stations.
There are six phone numbers - each phone number has it own account code, protocol
and events. The configured prefix is common to all six phone numbers. If a four-second
delay is specified in the prefix, the panel does not look for a dial tone, but performs blind-
dialling. The following scenarios are examples of how to set different modes of reporting.
5.5.1 Reporting to one phone number
The control panel reports events to one central station only. You specify settings for
phone number 1. Events for phone number 1 are enabled by default.
Level 1 Level 2 Value State
Phone Number
Phone Number 1 123456
Phone Number 2
Account Code Phone Number 1 445566
Phone Number 2
Protocol
Phone Number 1 SIA
Phone Number 2
Events
Phone Number 1 – Alarms
Enabled
Phone Number 1 – Alarm Restores
Enabled
Phone Number 1 – Tampers and Restores Enabled
Phone Number 2 – Alarms
Phone Number 2 – Alarm Restores
Phone Number 2 – Tampers and Restores
5.5.2 Backup reporting
Backup reporting configures the control panel to report to two or more central stations.
The first phone number belongs to the main central station and all other phone numbers
belong to the backup central stations. Events are reported to the first number but, if the
panel cannot reach this number, it dials the backup number(s). The control panel makes
two calls to each number in sequence. It performs the sequence for the number of times
specified in ARC Dial Attempts or until it receives a kiss off. The same account code is
used to report to all numbers. Events for phone number 1 are enabled by default and
events for phone numbers 2 - 6 are disabled by default. If phone number 1 and phone
number 2 are programmed, the default sequence is 1,1 2,2 1,1,2,2 for a total of eight
calls to each number.
Level 1 Level 2 Value State
Phone Number
Phone Number 1 123456
Phone Number 2 456789

GE CS5500 Specifications

General

Model	CS5500
Brand	GE
Display	LCD
Backlight	Yes
Power	12VDC
Type	Keypad
Compatibility	GE Security Systems

Summary

1 Introducing the CSx75 System

Getting Started

Provides an overview of the CSx75 system and initial setup procedures.

LCD Keypad (CS5500)

Details the functions and indicators of the CS5500 LCD keypad.

Other Methods of Programming

Explains alternative programming methods besides the menu system.

2 Programming the System

Powering Up the System

Explains initial system power-up and essential settings like language and defaults.

Entering Programming Mode

Guides on how to access the installer menu and navigate its levels.

Navigating the Menus

Details how to move through menu options using navigation keys.

Selecting a Menu Option

Describes how to select menu options and navigate forward or backward.

Changing a Menu Option

Explains how to modify selection list, binary, and numeric entries.

Changing Phone Numbers and Phone Prefixes

Details the process for editing phone numbers and prefixes.

Exiting the Menu System

Provides instructions on how to safely exit the programming menu.

Programming Map

Outlines the overall menu structure for system programming.

3 Editing Text

Overview

Explains the text editor and word library for customizing system messages.

Word Library

Details the word library feature for speeding up text entry.

Installer Message

Describes how to configure custom messages displayed on the keypad.

4 Programming with the UDx75 Software

Other Methods of Programming

Introduces programming via UDx75 software as an alternative method.

Connecting the Panel to the Computer

Details serial and modem connections for computer access.

Programming with Up/Download Software

Explains data transfer between panel and computer using software.

Programming Tasks

Lists various programming tasks and their corresponding UDx75 menu paths.

5 Advanced Programming

Multi-area Mode

Configures keypad operation for single or multiple area control.

Copying Zones

Enables copying zone settings to other zones for efficient configuration.

Modifying Existing Zone Types

Explains how to change input type, names, and attributes of zone types.

Setting up a Keypad to Use Multiple Languages

Details how to configure a keypad to support multiple languages.

Setting up a Communicator

Covers configuring reporting events to multiple central stations.

6 Programming a Sample System

The Sample System

Provides an overview of programming tasks for a basic system setup.

Setting up the System

Guides on setting up keypad partition, date/time, and enrolling modules.

Configuring the System

Details configuration of keypads, zones, and phone settings.

Programming the Wireless Modules

Covers defaulting and programming wireless detectors and modules.

7 Reading the Event Log

Reading the Event Log

Details how to access and view the system's event log.

8 Reference

Appendix 1: Reporting Fixed Codes in Contact ID or SIA

Lists event codes for Contact ID and SIA reporting formats.

Appendix 2: Overview of Module Numbers

Provides a list of module numbers for various system components.

Appendix 3: Output Events

Details selectable output events for control panel, expander, and power module.

Appendix 4: Communicator Formats

Lists selectable communication formats for central station reporting.

Appendix 5: Service Messages

Explains service messages and the actions required to resolve them.

Appendix 6: Tasks Summary

Summarizes tasks and the user authority required for each.

Appendix 7: Event Log Events

Provides explanations for various event messages found in the event log.

Appendix 8: Word Library Words

Lists the predefined words available in the keypad's word library.

9 Glossary
