S47183-e 01/2008 Design and specifications are subject to change without notice 13
Control box terminals
1x12-pole AC 400V, 20A
4x15-pole AC 250V, 8A
Closing solenoid drive
1)
Rated voltage AC 48V…230V and DC 48V…220V
Operating range 80%...115% of rated voltage
Power consumption Gerapid 2607 / 4207 1750W / 2000W
Power consumption Gerapid 6007 / 8007 2600W / 2600W
Minimal CLOSING command duration 100ms
min.interval between two "CLOSE" operations ~8s with NEKO installed; ~14s w/o NEKO
Internal voltage converter
1)
Input: Voltage range DC 33...85V
for Gerapid 2607, 4207, 6007, 8007
Output: Voltage range DC 24V (±5%)
Current 6A permanent
Model description PCMD 150 48 S24W-GE
Input: Voltage range DC 88...145V
Output: Voltage range DC 24V (±5%)
Current 6A permanent
Model description nr. PCMD 150 110 S24W-GE
Input: Voltage range AC 115...290V, DC 125...353V
Output: Voltage range DC 24V (±5%)
Current 3A permanent, 5A/100ms
Model description nr. PCMA 70 S24W-GE
External power supply
with plug and socket unit requires extrnal 24V (±5%) DC
Aux. contact HS 1…HS 10,
Rated operational voltage Ue/AC 230V
OCT- and Arc chute- indicators
Rated operational current Ie/AC-15 1A
Rated operational current Ie/AC-12 (Ith) 10A
Rated operational voltage Ue/DC 110V
Rated operational current Ie/DC-13 0,5A
Contact duty (min. value) DC 10V/2 mA
ST
1)
Rated voltage Uc 24V
(Shunt trip) Operating range: OFF 21.6V…26.4V
Power consumption ~ 150W
UVR
1)
Rated voltage Uc 24V
(Zero voltage release) Operating range: OFF < 3V
Operating range: ON 24V (±10%)
Power consumption ~ 40W
ED-tripping device
1)
Energie source: Capacity 2000µF
Charging voltage 300V
Switching interval max. 2/min with 10 consecutive operations
Endurance 1000 operations with 1operation per 180s
Firing signal
2)
level / duration
6…24V / 100…1000ms
1)
Standard ambient conditions acc. to EN 123-1 Attachement B. For meeting outside of this standard range, please call back.
Table 2a: Technical data of auxiliary circuits
Components Technical datas of control circuits
Us / In
SU-Control CLOSE-push-button -S1 DC 24V / approx. 10mA
ST releasing push-button-S2 DC 24V / approx. 4A
UVR releasing
push-button -S2 ( -X2 :6 / :7) DC 24V / approx. 10mA
push-button -S2 ( -X2 :8 / :9 ) DC 24V / approx. 450mA
ED-coil tripping w/o NEKO(R = 4Ohm)
push-button -S3 DC 300V / 750A / 3ms
ED-coil tripping with NEKO Connect "Firing signal" at ( -X2 :10 / :11 ) DC 6V…24V / approx.20mA
Table 2b: Control circuits ( directional values to rate the components )
