GE Gerapid 2607 User Manual

24 Design and specifications are subject to change without notice 01/2008
4.3.9 Auxiliary switches.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
X4
HS 1 HS 2 HS 3 HS 4 HS 5
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
X5
HS 6 HS 7 HS 8 HS 9 HS 10
Fig. 30 Auxiliary switches
Key position - 7
Key number – 1: With 3 switches (HS1...HS3).
Key number – 2: With 5 switches (HS1...HS5).
Key number – 3: With 10 switches (HS1...HS10)..
36/ _
_ _ _ _ X _
