S47183-e 01/2008 Design and specifications are subject to change without notice 27
5.1 Safety distances. Units call in mm (inches)
Type Arc chute Main- additional Deflector Safety distances / Insulated plates Safety distances / Earthed plates
Gerapid Connection isolation
action E A B C D A B C D
2607 / 4207
1x2
all
10 (0,4) 700 (27,6) 150 (5,9) 150 (5,9) 120 (4,7) 1000 (39,4) 300 (11,8) 300 (11,8) 300 (11,8)
1x3
all
1) 1) 1) 1) 1) - - - -
1x4
all
150 (5,9) 700 (27,6) 150 (5,9) 150 (5,9) 120 (4,7) 1350 (53,2) 450 (17,7) 450 (17,7) 200 (7,9)
2x2
all
80 (3,15) 1000 (39,4) 300 (11,8) 300 (11,8) 300 (11,8) 1350 (53,2) 450 (17,7) 450 (17,7) 300 (11,8)
2x3
all
80 (3,15) 1000 (39,4) 180 (7,1) 180 (7,1) 180 (7,1) - - - -
2x4
H / H Plate
150 (5,9) 1000 (39,4) 180 (7,1) 180 (7,1) 180 (7,1) - - - -
2x4
H / H Sidewalls
150 (5,9) 1000 (39,4) 180 (7,1) 180 (7,1) 180 (7,1) - - - -
2x4
SEL / H Pan
150 (5,9) 1000 (39,4) 180 (7,1) 180 (7,1) 180 (7,1) - - - -
6007
1x2
V / V Heat sink
10 (0,4) 1000 (39,4) 300 (11,8) 300 (11,8) 180 (7,1) - - - -
1x3
1) 1)
1) 1) 1) 1) 1) - - - -
1x4
V / V Heat sink
150 (5,9) 1000 (39,4) 300 (11,8) 300 (11,8) 180 (7,1) - - - -
2x2
V / V Heat sink
80 (3,15) 1000 (39,4) 180 (7,1) 180 (7,1) 180 (7,1) - - - -
2x3
V / V Heat sink
80 (3,15) 1000 (39,4) 180 (7,1) 180 (7,1) 180 (7,1) - - - -
2x4
1) 1)
1) 1) 1) 1) 1) - - - -
8007
1x2
V / V Heat sink
10 (0,4) 1000 (39,4) 300 (11,8) 300 (11,8) 180 (7,1) - - - -
1x3
1) 1)
1) 1) 1) 1) 1) - - - -
1x4
1) 1)
1) 1) 1) 1) 1) - - - -
2)
2x2
V / V Heat sink
80 (3,15) 1000 (39,4) 180 (7,1) 180 (7,1) 180 (7,1) - - - -
2)
2x3
V / V Heat sink
80 (3,15) 1000 (39,4) 180 (7,1) 180 (7,1) 300 (11,8) - - - -
2x4
1) 1)
1) 1) 1) 1) 1) - - - -
1)
will be checked by customers order
2)
acc. IEC 947-2 / ks-setting <12 kA
H
…Horizontal terminal V...Vertical terminal
SEL
...Current measurement system type SEL
Legend for dimensional drawings
K
Heat sink (for Gerapid 6007)
L
All openings respectively free areas on the top of the cubical shall be not less than 50%
M
Soleonid drive
P
Diameter 9 mm [0,35in], Countersunk screw M8
S
Control box
Z
Conrctor
