4.2 Basic Setup
The QuickPanel
+
Operator Interface is shipped ready for use after initial configuration.
To power up the unit, connect a dc power supply using the supplied quick-connect plug. Depending on the application,
you may also want to connect and configure optional input devices, communications ports, and expansion adapters.
Warning
To avoid personal injury or damage to equipment, ensure that the dc supply is
disconnected from power and the leads are not energized before attaching them to
the unit's power supply plug.
Warning
If this equipment is used in a manner not specified by the manufacturer,
equipment protection may be impaired.
Optional
Ethernet
Connection
Power
Supply
Serial
I/O
Optional Serial
I/O
Optional USB Keyboard and
Mouse
Basic Setup
Diagram
To Next Page
