GE QuickPanel+ IC755CxS06RDx User Manual

Operation
For public disclosure
GFK-2847W 91
6.1.3 Touchscreen Re-calibration
The QuickPanel
+
touchscreen is shipped pre-calibrated. However, if there are any issues with touchscreen
responsiveness, it may need to be re-calibrated.
➢ To re-calibrate the touchscreen
1. Open the QuickPanel
+
Setup tool.
2. Select the TouchPanel tab.
3. Select Recalibrate Touch Screen.
4. Select Recalibrate Touch Sensor.
Note During IC755CxS06RDx or IC755CxW07CDx touchscreen sensor re-calibration, the user is prompted to
activate a switch located in the battery compartment. This is not applicable to any other display units.
5. Remove the battery cover and press the switch.
Switch
Battery
Cover
6. Replace the battery
cover.
Touchscreen Sensor Calibration Switch
