QuickPanel⁺ Operator Interface User
Manual
5.6.2 IC755CxW07CDx
➢ To install or replace the battery for the IC755CxW07CDx
Caution
Replace the battery for the IC755CxW07CDx only with GE battery part number
IC755ACCBATT.
1. Remove the battery cover by pressing down while sliding outward.
IC755CxW07CDx Battery Cover Removal
2. Connect the battery harness connector to the header, noting keyed orientation.
Battery Part Number
IC755ACCBATT
Battery Harness Connection
3. Verify that the positive (red) connection is down and the negative (black) connection is up.
