5 Mounting and Installation
This chapter provides the following procedures to mount and install the QuickPanel
+
Operator Interface:
• Protective Sheet Installation
• Mounting Location
• Panel Mounting
• VESA Arm Mounting
• Battery Installation and Replacement
• Connectors
5.1 Protective Sheet Installation
➢ To install the protective sheet
1. Remove the protective film from the QuickPanel
+
display screen.
2. Wipe the display unit of any dust or fingerprints.
3. Peel back a corner of the clear side of the protective sheet.
4. Begin applying the corner to the display screen.
5. Slowly apply the rest of the protective sheet, smoothing out as you go.
6. Peel the green curing film from the protective sheet.
