gefran BDI50 Series User Manual

4-10
Group 00- The basic parameters group
No. Description Range
Factory
Setting
Unit Note
00-00
Control mode
0:V/F mode
0
-
1:SLV mode
00-01
Motor rotation
0:Forward
1:Reverse
0 - *1
00-02
Main Run
Source Selection
0:Keypad
1 -
1:External Run/Stop Control
2:Communication
00-03
Alternative Run
Source Selection
0:Keypad
0 -
1:External Run/Stop Control
2:Communication
00-04
Operation modes for
external terminals
0: Forward/Stop-Reverse/Stop
0 -
1: Run/Stop-Reverse/Forward
2: 3-Wire Control Mode-Run/Stop
00-05
Main Frequency
Source Selection
0: Frequency setting via ▼/▲ buttons
2 -
1:Potentiometer on keypad
2:External AVI Analog Signal Input
3:External ACI Analog Signal Input
4:External Up/Down Frequency
Control
5:Communication setting Frequency
6:PID output frequency
00-06
Alternative Frequency
Source Selection
0: Frequency setting via ▼/▲ buttons
0 -
1:Potentiometer on keypad
2:External AVI Analog Signal Input
3:External ACI Analog Signal Input
4:External Up/Down Frequency
Control
5:Communication setting Frequency
6:PID output frequency.
00-07
Main and Alternative
Frequency Command modes
0: Main Or Alternative Frequency
1: Main frequency+Alternative
Frequency
0 -
00-08
Communication
Frequency Command
0.00~599.00 Hz *4
00-09
Frequency command
Save mode
(Communication mode)
0:Save the frequency before power
down
1:Save the communication frequency
0 -
00-10
Initial Frequency
Selection ( keypad mode)
0:by Current Frequency Command
0 -
1:by 0 Frequency Command
2:by 00-11
00-11
Initial Frequency
Keypad mode
0.00~599.00 50.00/60.00 Hz
00-12
Frequency Upper Limit
0.01~599.00
50.00/60.00
Hz
00-13
Frequency Lower Limit
0.00~598.99
0.00
Hz
00-14
Acceleration Time 1
0.1~3600.0
10.0
s
*1
00-15
Deceleration Time 1
0.1~3600.0
10.0
s
*1
00-16
Acceleration Time 2
0.1~3600.0
10.0
s
*1
00-17
Deceleration Time 2
0.1~3600.0
10.0
s
*1
00-18
Jog Frequency
1.00~25.00
2.00
Hz
*1
00-19
Jog Acceleration Time
0.1~25.5
0.5
s
*1
00-20
Jog Deceleration Time
0.1~25.5
0.5
s
*1
