Page 57
DISASSEMBLY
SECTION 4.1
MAJOR DISASSEMBLY
PART 4
ITEM QTY. DESCRIPTION
1 1 ENGINE, 196CC
2 1 RECOIL ASSEMBLY
3 1 CARBURETOR
4 1 AIR CLEANER COVER
5 1 AIR FILTER
6 3 CARBURETOR GASKET
7 1 SPARK PLUG BOOT
8 1 OIL LEVEL SENSOR
9 1 FRAME, 1800W
10 1 FUEL SHUTOFF VALVE
11 2 VIBRATION MOUNT, #1
12 2 VIBRATION MOUNT, #2
13 1 AVR
14 1 BRUSH ASSEMBLY
15 1 SPARK ARRESTOR
16 1 MUFFLER ASSEMBLY
17 1 FUEL TANK ASSEMBLY
18 1 FUEL TANK CAP ASSEMBLY
19 1 CONTROL PANEL ASSEMBLY
20 1 ASSEMBLY, ALTERNATOR 1800W
ITEM QTY. DESCRIPTION
