20
GA-6KIEH-RH/GA-6KIEL-RH Motherboard
2-5: Connectors Introduction & Jumper Setting
1. ATX1 12. F_AUDIO1
2. IDE1 (IDE cable connector) 13. BAT1 (Battery)
3. SATA1 (SiI3114 SATA cable connector) 14. CPU_FAN1
4. SATA2 (SiI3114 SATA cable connector) 15. SYS_FAN1
5**.SATA3 (SiI3114 SATA cable connector) 16. F_Panel (Front Panel connector)
6**.SATA4 (SiI3114 SATA cable connector) 17. CLR_CMOS (Clear CMOS)
7. SATA5 (ICH8M SATA cable connector)
8. COM1
9. COM2
10. F_USB1 (Fornt USB cable connector)
11. F_USB2 (Fornt USB cable connector)
** For GA-6KIEH-RH Only
1
2
3
4
5
6
7
8
9
10 11
12
13
14
15
16
17
