43
BIOS Setup
Serial Port B
This allows users to configure serial prot B by using this option.
Enabled Enable the configuration (Default setting)
Disabled Disable the configuration.
Base I/O address
3F8/IRQ4 Set IO address to 3F8/IRQ4.
2F8/IRQ3 Set IO address to 2F8/IRQ3. (Default setting)
3E8/IRQ4 Set IO address to 3E8/IRQ4.
2E8/IRQ3 Set IO address to 2E8/IRQ3.
COM Port Address
If this option is set to enabled, it will use a port on the motherboard to runconsole redirection
function.
Onboard serial Port A Use Serial Port A as the COM port address.
Onboard serial Port B Use Serial Port B as the COM port address.
Disabled Disable this function. (Default setting)
Baud Rate
This option allows user to set the specified baud rate.
Options 300, 1200, 2400, 9600, 19.2K, 38.4K, 57.6K, 115.2K.
Console Type
This option allows user to select the specified terminal type. This is defined by IEEE.
Options VT100, VT100 8bit, PC-ANSI 7bit, VT100+, VT-UTF8
Flow Control
This option provide user to enable the flow control function.
None Not supported.
XON/OFF Software control.
CTS/RTS Hardware control. (Default setting)
Console Connection
This field indicates whether the console is connected directly to the system or a modem is
used to connect.
Direct Console is connected directly to the system. (Default setting)
To Next Page
