Gigabyte GA-6KIEH-RH User Manual

7
Introduction
1.2 Features Summary
Form Factor y 170mm x 170mm Mini ITX form factor, 8 layers PCB.
CPU y Supports single Intel
®
Merom/Penryn/Celeron M550 series
processor
(GA-6KIEH-RH) y Socket P with 533/800MHz
CPU y Supports single Intel
®
Celeron M550 series processor
(GA-6KIEL-RH) y Socket P with 533MHz
Chipset y Intel
®
GME965 MCH
(GA-6KIEH-RH) y Intel
®
ICH8M
Chipset y Intel
®
GLE960 MCH
(GA-6KIEL-RH) y Intel
®
ICH8M
Memory y 2 x DDR2 DIMM sockets
y Supports up to 4GB 533/667 memory (GA-6KIEH-RH)
y Supports up to 2GB 533 memory (GA-6KIEL-RH)
y Supports 1.8V DDR2 DIMMs
I/O Control y ITE IT8718F Super I/O
Expansion Slots y Supports 1 PCI slots 32-Bit/33MHz
y Supports 1 mini card slot (PCI-E x1/ USB 2.0)
y Supports 1 mini PCI slot (PCI 33Mhz)
SATA Controller y Built in Silicon Image
®
SiI 3114 with RAID 0,1,10, 5
(GA-6KIEH-RH) y Supports 5 SATA connectors (SiI3114 4 Ports, ICH8M 1 Port)
SATA Controller y Intel
®
ICH8M supports 3 SATA 3.0 Gb/s connectors
(GA-6KIEL-RH)
On-Board Graphic y Intel
®
GMA X3100 3D Graphic Engine (GA-6KIEH-RH)
y Intel
®
GMA X3000 3D Graphic Engine (GA-6KIEL-RH)
y Shared system memory up to 256MB
Internal Connector y 1 x 20-pin ATX power connector
y 5 x SATA connectors
y 1 x IDE connector
y 2 x Serial connectors (COM)
y 1 x front audio connector
y 2 x USB 2.0 connectors for additional 4 ports by cable
y 1 x front panel connecctor
y 1 x System fan cable connector
y 1 x CPU fan cable connector
