Gigabyte GA-X58A-UD3R User Manual

- 39 - BIOS Setup
2-3 MB Intelligent Tweaker(M.I.T.)
(Note 1) This item appears only if you install a CPU that supports this feature.
(Note 2) This item appears only if you install a memory module that supports this feature.
Whether the system will work stably with the overclock/overvoltage settings you made is dependent
onyouroverallsystem congurations.Incorrectlydoing overclock/overvoltagemayresultindam-
age to CPU, chipset, or memory and reduce the useful life of these components. This page is for
advanced users only and we recommend you not to alter the default settings to prevent system
instability or other unexpected results. (Inadequately altering the settings may result in system's
failure to boot. If this occurs, clear the CMOS values and reset the board to default values.)
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
MB Intelligent Tweaker(M.I.T.)
CPU Clock Ratio
(Note 1)
[22X]
CPU Frequency 2.93GHz(133x22)

Advanced CPU Features [Press Enter]
QPI Clock Ratio [Auto]
QPI Link Speed 4.8GHz

UnCore & QPI Features [Press Enter]
Base Clock(BCLK) Control [Disabled]
x BCLK Frequency (Mhz) 133

Advanced Clock Control [Press Enter]
Performance Enhance [Turbo]
 ExtremeMemoryProle(X.M.P.)
(Note 2)
[Disabled]
System Memory Multiplier (SPD) [Auto]
Memory Frequency (Mhz) 1066 1066
DRAM Timing Selectable (SPD) [Auto]
 ProleDDRVoltage   1.5V
 ProleQPIVoltage   1.15V
>>>>> Channel A
x CAS Latency Time 8 Auto
x tRCD 8 Auto
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level

CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
MB Intelligent Tweaker(M.I.T.)
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level

x tRP 8 Auto
x tRAS 20 Auto
x Command Rate(CMD) 1 Auto
>>>>> Channel B
x CAS Latency Time - Auto
x tRCD - Auto
x tRP - Auto
x tRAS - Auto
x Command Rate(CMD) - Auto
>>>>> Channel C
x CAS Latency Time - Auto
x tRCD - Auto
x tRP - Auto
x tRAS - Auto
x Command Rate(CMD) - Auto

Advanced DRAM Features [Press Enter]
Voltage Types Normal Current
-----------------------------------------------------------------------------
Load-Line Calibration [Standard]

Gigabyte GA-X58A-UD3R Specifications

General

Non-ECC	Yes
Memory voltage	1.5 V
Number of memory slots	6
Maximum internal memory	24 GB
Processor socket	Socket B (LGA 1366)
Processor manufacturer	Intel
USB 2.0 connectors	2
Number of SATA connectors	10
USB 2.0 ports quantity	4
VGA (D-Sub) ports quantity	0
Audio chip	Realtek ALC889
Motherboard form factor	ATX
Compatible operating systems	Windows 7/Vista/XP
On-board graphics card	No
Bundled software	Norton Internet Security
Networking features	10/100/1000 Mbit/s
ACPI version	1.0

Weight and Dimensions

Depth	244 mm
Width	305 mm
