Gigabyte GA-X79-UD5 User Manual

Hardware Installation - 10 -
 
CPU Support for Intel 
®
Core
™
i7 processors in the LGA2011 package
(Go to GIGABYTE's website for the latest CPU support list.)
L3 cache varies with CPU 
Chipset Intel 
®
X79 Express Chipset
Memory 8 x 1.5V DDR3 DIMM sockets supporting up to 64 GB of system memory 
* Due to Windows 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than 4 GB.
4 channel memory architecture 
Support for DDR3 2133/1866/1600/1333/1066 MHz memory modules 
Support for non-ECC memory modules 
 
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Audio Realtek ALC898 codec 
 
2/4/5.1/7.1-channel 
Support for Dolby 
®
Home Theater
Support for S/PDIF Out 
LAN 1 x Intel GbE LAN phy (10/100/1000 Mbit) 
Expansion Slots 2 x PCI Express x16 slots, running at x16 (PCIEX16_1/PCIEX16_2) 
* For optimum performance, if only one PCI Express graphics card is to be installed, be
sure to install it in the PCIEX16_1 slot; if you are installing two PCI Express graphics
cards, it is recommended that you install them in the PCIEX16_1 and PCIEX16_2
slots.
1 x PCI Express x16 slot, running at x8 (PCIEX8) 
(All PCI Express x16 slots conform to PCI Express 3.0 standard.)
2 x PCI Express x1 slots 
(All PCI Express x1 slots conform to PCI Express 2.0 standard.)
1 x PCI slot 
Multi-Graphics
Technology
Support for 3-Way/2-Way AMD CrossFireX 
™
/NVIDIA SLI technology
* The PCIEX16_1/PCIEX16_2 slots operate at up to x8 mode when 3-Way AMD
CrossFireX
™
/NVIDIA SLI is enabled.
Storage Interface Chipset: 
- 2 x SATA 6Gb/s connectors (SATA3 0/SATA3 1) supporting up to 2 SATA
6Gb/s devices
- 4 x SATA 3Gb/s connectors (SATA2 2~SATA2 5) supporting up to 4 SATA
3Gb/s devices
- Support for RAID 0, RAID 1, RAID 5, and RAID 10
* When a RAID set is built across the SATA 6Gb/s and SATA 3Gb/s channels, the
system performance of the RAID set may vary depending on the devices being
connected.

Gigabyte GA-X79-UD5 Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Quad-channel
Number of memory slots	8
Supported memory types	DDR3-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	1066, 1200, 1300, 1333, 1500, 1600, 1666, 1800, 1866, 1900, 2000, 2133 MHz
Processor socket	LGA 2011 (Socket R)
Processor manufacturer	Intel
Compatible processor series	Intel® Core™ i7
USB 2.0 connectors	3
Number of SATA II connectors	4
Number of SATA III connectors	6
Number of Parallel ATA connectors	0
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit
Headphone outputs	5
eSATA ports quantity	2
USB 2.0 ports quantity	7
Audio chip	Realtek ALC898
Component for	PC
Power source type	ATX
Audio output channels	7.1 channels
Motherboard form factor	Extended ATX
Compatible operating systems	Windows 7/Vista/XP
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Parallel processing technology support	2-Way SLI, 3-Way SLI, Hybrid CrossFireX
PCI Express slots version	3.0
Wi-Fi standards	Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Networking features	10/100/1000 Mbit/sec
Ethernet interface type	Gigabit Ethernet

Weight and Dimensions

Depth	264 mm
Width	305 mm
