Appendix - 100 -
(Note) Enter the Digital Output(Optical)
connector(s) on the back panel for digital audio output or enter the Digital Output screen if you use
the internal S/PDIF Out connector (SPDIF_O) for digital audio output.
The S/PDIF Out jack can transmit audio signals to an external decoder for decoding to get the best audio
quality.
1. Connecting a S/PDIF Out Cable:
Connect a S/PDIF optical cable to the corresponding S/PDIF out connector as shown below and an external
decoder for transmitting the S/PDIF digital audio signals.
On the Digital Output(Optical) screen
(Note)
, click the Default Format tab and then select the sample rate and
bit depth. Click OK to complete.
Connects to a S/PDIF optical cable
To Next Page
