Gree GEH(12)AA-K3DNA1C/I User Manual

Super Free Match
Service Manual
PRODUCT
7
4 PRODUCT DATA
4.1 Product Data of Outdoor Unit
Model Heat pump GWHD(48S)NM3CO GWHD(56S)NM3CO
Cooling capacity KW 14.0 16.0
Heating capacity KW 16.0 18.0
Cooling KW 4.40 5.0
Nominal input
Heating KW 4.25 4.7
EER/COP 2.9/3.2 2.8/3.5
Minimum NO. of connectable indoor units 2 2
Maximum NO. of connectable indoor units 8 9
Minimum No. of BU modules to be connected 1 1
Maximum No. of BU modules to be connected 3 3
Min 50 50
Total capacity index of to be connected
indoor units
Max 135 135
Power supply 3Ph,380~415V, 50Hz
Dimensions (H×W×D) mm 1345×900×340 1345×900×340
Net weight/Gross weight kg 116/125 116/125
Sound pressure level cooling/heating dB(A) 58 58
Type Axial-flow
Fan
Air Flow Volume m
3
/h 7000 7000
Name R410A
Charge kg 4.95 4.95
Refrigerant
Control Electronic expansion valve
Type FV50S FV50S
Refrigerant oil
Charge L 1.35 1.35
Type Inverter Rotary
Compressor
Quantity 1
Gas mm Φ15.9 Φ19.05
Piping connections
Liquid mm Φ9.52 Φ9.52
System total m 135 145
OU-BU m 55
total
BU-IN m 80 90
Piping length
1 room BU-IN m 15
OU-BU m 30
OU-IN m 30
Height
BU-BU/
IN-IN
m 15
Cooling DB℃ 18~48
Operation range
Heating ℃DB -10～24
20' GP 25 25
40' GP 50 50
Loading quantity
40' HQ 50 50

Gree GEH(12)AA-K3DNA1C/I Specifications

General

Brand	Gree
Model	GEH(12)AA-K3DNA1C/I
Category	Air Conditioner
Language	English
