Super Free Match
Service Manual
INSTALLATION65
2 FLOW CHART OF INSTALLATION
Design kicking-off
Material selection
Inspection of site installation position
Installation of indoor unit Installation of outdoor unit Installation of BU module
Installation of
remote
controller
Connection of
power cables
Installation of drainage pipes
Thermal insulation of connection pipes and drainage pipes
Installation of refrigerant pipes
Connection of
transmission
line
Connection of
power cables
Connection of
transmission
line
Assign the
address
Vacuum the system through
the gas and liquid valves
Open the valves
Refrigerant charging
Test run
As-bulit drawing
Delivery of the operating instructions
Installation of
piping adapter
Connection of
power cables
Leakage test
Commissioning of complete unit
