Gree GEH(12)AA-K3DNA1C/I User Manual

Super Free Match
Service Manual
MAINTENANCE
N
143
Temp.
（℃）
Resistance
(kΩ)
Voltage
(15K/5V)
Voltage
(15K/3.3V）
Temp.
（℃）
Resistance
(kΩ)
Voltage
(15K/5V)
Voltage
(15K/3.3V）
61 3.579 4.037 2.664 66 2.998 4.167 2.750
62 3.454 4.064 2.682 67 2.898 4.190 2.766
63 3.333 4.091 2.700 68 2.797 4.214 2.781
64 3.217 4.117 2.717 69 2.702 4.237 2.796
65 3.105 4.143 2.734 70 2.611 4.259 2.811
5.2 20 KΩ
Temp.
（℃）
Resistance
(kΩ)
Voltage
(15K/5V)
Voltage
(15K/3.3V）
Temp.
（℃）
Resistance
(kΩ)
Voltage
(15K/5V)
Voltage
(15K/3.3V）
-30 361.8 0.262 0.173 2 59.08 1.265 0.835
-29 339.8 0.278 0.183 3 56.19 1.313 0.866
-28 319.2 0.295 0.195 4 53.46 1.361 0.898
-27 300 0.313 0.206 5 50.87 1.411 0.931
-26 282.2 0.331 0.218 6 48.42 1.462 0.965
-25 265.5 0.350 0.231 7 46.11 1.513 0.998
-24 249.9 0.371 0.245 8 43.92 1.564 1.033
-23 235.3 0.392 0.259 9 41.84 1.617 1.067
-22 221.6 0.414 0.273 10 39.87 1.670 1.102
-21 208.9 0.437 0.288 11 38.01 1.724 1.138
-20 196.9 0.461 0.304 12 36.24 1.778 1.174
-19 181.4 0.497 0.328 13 34.57 1.833 1.209
-18 171.4 0.522 0.345 14 32.98 1.888 1.246
-17 162.1 0.549 0.362 15 31.47 1.943 1.282
-16 153.3 0.577 0.381 16 30.04 1.998 1.319
-15 145 0.606 0.400 17 28.68 2.054 1.356
-14 137.2 0.636 0.420 18 27.39 2.110 1.393
-13 129.9 0.667 0.440 19 26.17 2.166 1.429
-12 123 0.699 0.462 20 25.01 2.222 1.466
-11 116.5 0.733 0.484 21 23.9 2.278 1.503
-10 110.3 0.767 0.507 22 22.85 2.334 1.540
-9 104.6 0.803 0.530 23 21.85 2.389 1.577
-8 99.13 0.839 0.554 24 20.9 2.445 1.614
-7 94 0.877 0.579 25 20 2.500 1.650
-6 89.17 0.916 0.605 26 19.14 2.555 1.686
-5 84.61 0.956 0.631 27 18.32 2.610 1.722
-4 80.31 0.997 0.658 28 17.55 2.663 1.758
-3 76.24 1.039 0.686 29 16.8 2.717 1.793
-2 72.41 1.082 0.714 30 16.1 2.770 1.828
-1 68.79 1.126 0.743 31 15.43 2.822 1.863
0 65.37 1.171 0.773 32 14.79 2.874 1.897
1 62.13 1.218 0.804 33 14.18 2.926 1.931
