Gree GEH(12)AA-K3DNA1C/I User Manual

Super Free Match
Service Manual
PRODUCT
2
PRODUCT
1 MODELS LIST
1.1 Outdoor Unit
Capacity Capacity Power supply
Model Product code
Cooling
(kW)
Heating
(kW)
Refriger
ant
Ph, V, Hz
Appearance
GWHD(48S)NM
3CO
CN860W0110 14.0 16.0
GWHD(56S)NM
3CO
CN860W0120 16.0 18.0
R410A 3,380~415,50
1.2 BU Module
Number of connectable
indoor units
Power supply
Model Product code
Min Max
Refrigerant
Ph, V, Hz
Appearance
FXB3A-K EN0130050 1 3
FXB5A-K LN01300220 1 5
R410A 1,220~240,50
1.3 Indoor Unit
1.3.1 Wall mounted type
¾ Hansol
Capacity Power supply
Model Product code
Cooling
(kW)
Heating
(kW)
Refrige
rant
Ph, V, Hz
Appearance
GWH(07)TA-K3DNA1E/I
CB148N05201 2.1 2.6
GWH(09)TA-K3DNA1E/I
CB148N05301 2.5 2.75
GWH(12)TB-K3DNA1E/I
CB148N05401 3.5 3.65
GWH(18)TC-K3DNA1E/I
CB148N05501 5.3 5.6
GWH(28)TD-K3DNA1C/I
CB148N07900 8.4 8.6
R410A 1,220~240,50
