Super Free Match
Service Manual
MAINTENANCE
144
Temp.
（℃）
Resistance
(kΩ)
Voltage
(15K/5V)
Voltage
(15K/3.3V）
Temp.
（℃）
Resistance
(kΩ)
Voltage
(15K/5V)
Voltage
(15K/3.3V）
34 13.59 2.977 1.965 55 5.942 3.855 2.544
35 13.04 3.027 1.998 56 5.726 3.887 2.565
36 12.51 3.076 2.030 57 5.519 3.919 2.586
37 12 3.125 2.063 58 5.32 3.949 2.607
38 11.52 3.173 2.094 59 5.13 3.979 2.626
39 11.06 3.220 2.125 60 4.948 4.008 2.646
40 10.62 3.266 2.155 61 4.773 4.037 2.664
41 10.2 3.311 2.185 62 4.605 4.064 2.682
42 9.803 3.355 2.215 63 4.443 4.091 2.700
43 9.42 3.399 2.243 64 4.289 4.117 2.717
44 9.054 3.442 2.272 65 4.14 4.143 2.734
45 8.705 3.484 2.299 66 3.998 4.167 2.750
46 8.37 3.525 2.326 67 3.861 4.191 2.766
47 8.051 3.565 2.353 68 3.729 4.214 2.781
48 7.745 3.604 2.379 69 3.603 4.237 2.796
49 7.453 3.643 2.404 70 3.481 4.259 2.811
50 7.173 3.680 2.429 71 3.364 4.280 2.825
51 6.905 3.717 2.453 72 3.252 4.301 2.838
52 6.648 3.753 2.477 73 3.144 4.321 2.852
53 6.403 3.787 2.500 74 3.04 4.340 2.865
54 6.167 3.822 2.522 75 2.94 4.359 2.877
5.3 50 KΩ
Temp.
（℃）
Resistance
(kΩ)
Voltage
(15K/5V)
Voltage
(15K/3.3V）
Temp.
（℃）
Resistance
(kΩ)
Voltage
(15K/5V)
Voltage
(15K/3.3V）
-30 911.56 0.054 0.036 -14 342.83 0.142 0.094
-29 853.66 0.058 0.038 -13 323.94 0.150 0.099
-28 799.98 0.062 0.041 -12 306.23 0.158 0.104
-27 750.18 0.066 0.043 -11 289.61 0.167 0.110
-26 703.92 0.070 0.046 -10 274.02 0.176 0.116
-25 660.93 0.075 0.049 -9 259.37 0.186 0.123
-24 620.94 0.079 0.052 -8 245.61 0.196 0.129
-23 583.72 0.084 0.056 -7 232.67 0.206 0.136
-22 549.04 0.089 0.059 -6 220.5 0.217 0.143
-21 516.71 0.095 0.063 -5 209.05 0.228 0.151
-20 486.55 0.101 0.066 -4 198.27 0.240 0.158
-19 458.4 0.107 0.070 -3 188.12 0.252 0.167
-18 432.1 0.113 0.075 -2 178.65 0.265 0.175
-17 407.51 0.120 0.079 -1 169.68 0.278 0.184
-16 384.51 0.127 0.084 0 161.02 0.292 0.193
-15 362.99 0.134 0.088 1 153 0.307 0.202
To Next Page
