80DWFK6HULHV'&
,QYHUWHU6HUYLFH0DQXDO
71
and quantity of accessory parts are correct.
Ɣ
Determine the correct handling route and methods, thus to avoid damaging the unit or causing
possible hazard. For the sake of protection and safety, it is suggested to move the unit with the packaging
box. Even though it is not permitted to do like this under special occasions, do not remove the packaging
box, thus to avoid loosening or falling during handling.
Ɣ
&RQ¿UPLIWKHLQVWDOOLQJIRXQGDWLRQLVVROLG:KHQWKLVXQLWLVWREHLQVWDOOHGRQWKHPHWDOVHFWLRQRIWKH
building, make sure that the electrical insulation must comply with applicable standards.
Ɣ
Ensure that the place of installation is far from the area where the inflammable or explosive
VXEVWDQFHVDUHVWRUHGWKXVWRDYRLGSRVVLEOHH[SORVLRQRU¿UHGXHWROHDNDJH
2.2 Installation Site
Ɣ
To ensure the unit in proper function, selection of installation location must be in accordance with
following principles:
Ɣ
Outdoor unit shall be installed so that the air discharged by outdoor unit will not return and that
VXI¿FLHQWVSDFHIRUUHSDLUVKDOOEHSURYLGHGDURXQGWKHPDFKLQH
Ɣ
The installation site must have good ventilation, so that the outdoor unit can take in and exhaust
enough air. Ensure that there is no obstacle for the return air inlet and exhaust of the outdoor unit. If there is
any obstacle blocking the return air inlet or exhaust, remove it.
Ɣ
Place of installation shall be strong enough to support the weight of outdoor unit, and it shall be
able to insulate noise and prevent vibration. Ensure that the wind and noise from the unit will not affect your
neighbors.
Ɣ
Avoid direct sunshine over the unit. It is better to set up a sun shield as the protection.
Ɣ
Place of installation must be able to drain the rainwater and defrosting water.
Ɣ
Place of installation must ensure the machine will not be buried under snow or subject to the
LQÀXHQFHRIUXEELVKRURLOIRJ
Ɣ
The installation site must be at a place where the air exhaust outlet does not face strong wind.
Ɣ
he outdoor unit must be lifted by using the designated lift hole. During lifting, take care to protect the
air conditioner and avoid knocking the metal parts, thus to prevent rusting in the future.
Ɣ
To meet the noise and vibration requirements, the outdoor unit shall be installed by using rubber
damping pad or spring damper.
Ɣ
The installing dimension shall comply with the installation requirements in these instructions. The
RXWGRRUXQLWPXVWEH¿[HGDWWKHLQVWDOOLQJSRVLWLRQ
Ɣ
The installation shall be done by specialist technicians.
2.3 Caution for Installation
Ɣ
7KHRXWGRRUXQLWVKDOOEHVRLQVWDOOHGWKDWWKHDLUGLVFKDUJHGRXWRIWKHRXWGRRUXQLWZLOOQRWÀRZEDFN
and that enough space shall be maintained around the machine for repair;
Ɣ
The installing position shall be in good ventilation, so that the machine can breathe and exhaust
enough air. Ensure that there is no obstruction at the inlet and outlet of the machine. If any, please remove
the obstructions blocking the air inlet and outlet.
Ɣ
,IWKHRXWGRRUXQLWLVLQVWDOOHGRQFRQFUHWHRUVROLGJURXQGLWVKDOOEH¿[HGE\XVLQJ0EROWVDQG
nuts. And ensure that the machine is kept vertical and horizontal.
Ɣ
The outdoor unit must be lifted by using the designated lift hole. During lifting, take care to protect the
air conditioner and avoid knocking the metal parts, thus to prevent rusting in the future.
Ɣ
To meet the noise and vibration requirements, the outdoor unit shall be installed by using rubber
damping pad or spring damper.
Ɣ
To install the drainage pipe, please insert the drainage joint to the drainage hole on the outdoor
chassis and connect a drainage pipe on the drainage joint. (The installing height of outdoor unit shall be at
least 5cm if drainage joint is to be used).
Ɣ
To insert the pipe through the wall, the wall-cross tube must be installed.
Ɣ
The installing dimension shall comply with the installation requirements in these instructions. The
RXWGRRUXQLWPXVWEH¿[HGDWWKHLQVWDOOLQJSRVLWLRQ
Ɣ
The installation shall be done by specialist technicians.
