KFR-20W/NA51 KF-20W/NA51
1Front grill 22413010224130101
2Front plate 22263005222630051
3Guide collar
10373001103730011
4Axial-flow vane 10333412103334121
5Motor FW25E 15013151150131511
6Motor supporter 01703074017030741
7Support plate 01793003017930031
8Electric box cover 01413012014130121
9Condenser components 0110315720110336511
10Rear plate 22263006222630061
11Electric box assy 01403027801403040341
124-way valve 430004021/1
134-way valve fittings
43000400/1
14Capillary assy 0300337930300335431
15Right handle 26233001262330011
16Valve supporter 01713058017130581
17Valve 1/4" 07100149 071001491
18Valve 3/8" 07100135 07100135 1
19Compressor C-1RN70H5C 00100354001003541
20Compressor absorb collar 76710212767102123
213-phase terminal board T386A 42011241 420112411
22Wire clamp 71010103710101031
23Fan capacitance 33010026 33010026 1
24Terminal board 2-8 42011103/1
25Capacitance clamp
02140001021413751
26Compressor capacitance 33000002330000021
27Separator assy
0123341730123341731
28Chassis assy 0120320910120320911
29Drainage joint of outdoor unit 06123401061234011
30Compressor overload 00180007001800071
No. Names of Materials
Codes of Materials
Amount
Detail of Components of Plastic Case Outdoor Unit
Bird Single-Split Type
