Operation procedures/pictures
Disassemble the motor and motor support
Fig.
Fig.
Motor
Motor support
Solder joint
Nut
Use screwdriver to screw off the screws which fix the
motor and motor support, can take off the motor and
(As shown in Fig.8-19)
motor support.
Disassemble the 4-way valve
(Only for condenser)
To unsolder 4 pcs solder joint of the 4-way valve,
then use spanner to screw off 1pc nut of the loop
from the 4-way valve, can disassemble the 4-way
valve. (As shown in Fig. 8-20)
