ENGLISH
76
Connecting an external device
With a digital audio/video signal
7
Suitable devices: Digital satellite receiver,
game console, BluRay player, DVD player/
recorder, set-top box, notebook, PC.
7
Video signal: digital image; definition: stan-
dard 576p; HDTV 720p, 1080i, 1080p.
7
Audio signal: digital sound (stereo, multichan-
nel compression, uncompressed).
7
Channel position »HDMI1«, »HDMI2«
»HDMI3«.
1 Connect the HDMI1, HDMI2 or HDMI3
(ARC) socket on the television and the
corresponding HDMI socket on the external
device using a standard HDMI cable (digi-
tal video and audio signal).
With an analogue video signal (pro-
gressive)
7
Suitable devices: DVD player/recorder, game
console.
7
Video signal: YUV; definition: standard 576p;
HDTV 720p, 1080i, 1080p.
7
Audio signal: stereo, analog.
7
Channel position »Component«.
1 Connect the AV / S-VHS /COMPONENT
sockets on the television and the corre-
sponding sockets on the external device
using Scart-YUV converter (video and audio
signal).
Using the Euro/AV socket
7
Suitable devices: Digital satellite receiver,
DVD player/recorder, set-top box, game
console, video recorder, decoder.
7
Video signal: CVBS/RGB.
7
Audio signal: stereo, analog.
7
Channel position »SCART«.
1 Connect the AV / S-VHS /COMPONENT
input on the television to the corresponding
socket on the external device using EURO/
AV cable (video and audio signal).
USING EXTERNAL DEVICES
---------------------------------------------------------------
Selecting Scart volume adjustment
1 Open the menu with »MENU«.
2 Select menu item »Settings« with »
V «, » Λ «,
»
<
« or »
>
« and press »OK« to confirm.
3 Select the menu item »Sound« with »
>
« or
»
<
« and press » V « to confirm.
4 Select the line »Advanced« with »
V « or
»
Λ « and press »OK« to confirm.
5 Select the line »Scart Output« with »
V « or
»
Λ «.
6 Select the option »Fixed« or »Adjustable«
with »
<
« or »
>
«.
Note:
7
»Scart Volume« becomes active when »Ad-
justable« is selected in the menu.
7 Select the line »Scart Volume« with »
V « or
»
Λ « and adjust the volume by using »
<
«
or »
>
«.
8 Press »EXIT« to end the setting.
With S-Video signal
7
Suitable devices: DVD player/recorder, video
recorder, camera recorder, notebook, PCs.
7
Video signal: Y/C.
7
Audio signal: stereo, analog.
7
Channel position »S-VIDEO«.
1 Connect the AV/S-VHS/COMPONENT
socket on the television to the corresponding
socket on the external device using EURO/
AV cable (video and audio signal).
