Harman Kardon AVR 70 User Manual

Front Panel Information Display
5
ENGLISH
¡ “Visual” Indicator: These
indicators display which video source is
being fed to the video monitor output.
™ Test: This indicator flashes when
the output levels are being set using
the built in test signal generator.
£ Memo: This indicator flashes when
the Memo button is pressed when
entering presets and other information
into the tuner’s memory.
¢ Auto: This indicator signifies that
the Automatic Receiving mode
(Stereo/Mono) is in use for FM
broadcasts.
∞ Tuned: This indicator lights when
an AM or FM station is properly tuned
and locked.
§ Stereo: This indicator lights when
an FM station is broadcasting in
stereo.
¶ Volume Indication: The last two
indicators on the information display
indicate the volume level. Note that
0dB is the reference level, not an
indication that there is no output.
• Tuner Frequency Indication:
When the tuner is in use, the main
Information Display will show the
preset channel number, if any, the
frequency band and the station
frequency. Indicators at the right side
of the display show
kHz when an LW
or MW station is tuned or
MHz when
an FM station is tuned.
ª Main Information Display: This
ten digit display shows messages
relating to the status, input source,
surround mode, tuner, volume level or
other aspects of the unit’s operation.
‚ DISP: This indicator lights when
the FL display has been turned
off using the Display button ) to
remind you that the unit is still
turned on.
⁄ P-Scan: This indicator flashes
when the stations programmed into
the tuner memory are being
automatically reviewed.
¤ Auto Memo: This indicator flashes
when the tuner is automatically
scanning for stations and entering
them into the preset memory.
‹ Mode Status: These indicators
display the currently selected
surround mode.
› Signal Level Indication: This is a
visual indication of the strength of a
radio station signal. The more bars
visible, the stronger the station.
AVR70 engelsk manual 11/01/98 11:57 Side 5

Harman Kardon AVR 70 Specifications

General

Impedance	75 Ω
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	95 dB
Total Harmonic Distortion (THD)	0.1 %
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	3
Line-in	Yes
Audio (L/R) in	1
Digital audio optical in	2
Connectivity technology	Wired
Speakers connectivity type	-
Ethernet LAN	No
AM band range	520 - 1720 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby TrueHD, DTS-HD Master Audio
Volume control	Digital
Apple docking compatibility	Not supported
AC input voltage	220 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	280 W
Cables included	AC

Weight and Dimensions

Depth	330 mm
Width	440 mm
Height	125 mm
Weight	9100 g
