Harman Kardon AVR 70 User Manual

Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Unpacking and Installation . . . . . . . . . . . . . . . . 3
Conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Front Panel Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Front Panel Information Display . . . . . . . . . . . . . . . . . . 5
Rear Panel Audio & Systems Connections . . . . . . . . . . . 6
Rear Panel Video Connections . . . . . . . . . . . . . . . . . . . . 7
Remote Control Functions . . . . . . . . . . . . . . . . . . . . . 8–9
Installation, Set Up and Configuration . . . . . . . . . 10–11
Remote Control Programming and Operation . . . 12–13
System Configuration. . . . . . . . . . . . . . . . . . . . . . . 14–16
Basic Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . 17–22
Source Selection . . . . . . . . . . . . . . . . . . . . . . . . 17
Volume Control. . . . . . . . . . . . . . . . . . . . . . . . . 17
Surround Mode Selection. . . . . . . . . . . . . . 17–18
TV Auto Function . . . . . . . . . . . . . . . . . . . . . . . 18
Tuner Operation. . . . . . . . . . . . . . . . . . . . . 18–20
RDS Operation . . . . . . . . . . . . . . . . . . . . . . 21–22
On Screen Display. . . . . . . . . . . . . . . . . . . . . . . . . . 23–24
Advanced Functions . . . . . . . . . . . . . . . . . . . . . . . . 25–26
Audio/Video Simulcast . . . . . . . . . . . . . . . . . . . 25
Delay Time Adjust. . . . . . . . . . . . . . . . . . . . . . . 25
Surround Mode Chart. . . . . . . . . . . . . . . . . . . . 26
Troubleshooting Chart . . . . . . . . . . . . . . . . . . . . . . . . . 27
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . 28
AVR70 engelsk manual 11/01/98 11:57 Side 6

Harman Kardon AVR 70 Specifications

General

Impedance	75 Ω
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	95 dB
Total Harmonic Distortion (THD)	0.1 %
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	3
Line-in	Yes
Audio (L/R) in	1
Digital audio optical in	2
Connectivity technology	Wired
Speakers connectivity type	-
Ethernet LAN	No
AM band range	520 - 1720 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby TrueHD, DTS-HD Master Audio
Volume control	Digital
Apple docking compatibility	Not supported
AC input voltage	220 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	280 W
Cables included	AC

Weight and Dimensions

Depth	330 mm
Width	440 mm
Height	125 mm
Weight	9100 g
