Technical Specifications
28
ENGLISH
Audio Section
Stereo Mode
Continuous Average Power (FTC)
80 Watts per channel 20Hz–20kHz:
@ < 0.09% THD, both channels driven into 8 Ohms
Five Channel Surround Mode
Continuous average power per channel (FTC)
Front L&R channels:
70 Watts per channel from 20Hz–20KHz,
@ < 0.15% THD, both channels driven into 8 Ohms
Center channel:
70 Watts from 20Hz–20kHz,
@ < 0.15% THD, driven into 8 Ohms
Surround channels:
25 Watts per channel from 40Hz–20kHz,
@ < 0.15% THD, both channels driven into 8 Ohms
Input Sensitivity/Impedance
Linear 220mV/50 Kohms
Signal to Noise Rate (IHF-A)
Linear 95 dB
Dolby Surround
Channel Separation 40dB
FM Tuner Section
Frequency Range 87.5–108.0MHz
Usable Sensitivity IHF 1.3 µV/13.5dBf
Signal to Noise Ratio Mono/Stereo 76/68dB
Distortion Mono/Stereo 0.2/0.5%
Stereo Separation 1 kHz 40dB
Alternate Channel
Selectivity (±300kHz) 55dB
Image Rejection 98MHz: 70dB
AM Tuner Section
Frequency Range 531–1602/152–282kHz
Signal-to-Noise Ratio 50dB
Usable Sensitivity Loop: 500µV (MW)/1,500 µV (LW)
Distortion 1kHz, 30% Mod: 0.5%
Selectivity ±18kHz 70dB
Video Section
Television Format PAL, SECAM, NTSC
Input Level/Impedance 1Vp-p/75ohms
Output Level/Impedance 1Vp-p/75ohms
Video Frequency Response 10Hz to 8MHz (–3dB)
S/N 65dB
General
Power Requirement AC 230V 50Hz
Power Consumption 40W idle, 530W maximum
Dimension (Max)
Width 440 mm (17.4 inches)
Height 160 mm (6.4 inches)
Depth 459 mm (18 inches)
Weight 12.3 kg (27 lbs.)
All features and specifications are subject to change without notice.
Manufactured under license from Dolby Laboratories Licensing Corporation.
Additionally licensed under one or more of the following patents:
U.S. numbers 3,632,886, 3,746,792 and 3,959,590;
Canadian numbers 1,004,603 and 1,037,877.
“Dolby” and the double-D symbol are registered trademarks
of Dolby Laboratories Licensing Corporation.
AVR70 engelsk manual 11/01/98 11:57 Side 28
