Thermal Monocular User Manual
17
Figure 3-5 Set PIP Mode
Note
If the PIP function is enabled, only the PIP view zooms when adjusting the
digital zoom ratio.
3.11
Adjust Digital Zoom
You can zoom in and out the image by using this function. Press in
the live view interface, the digital zoom ratio switches between 1×, 2×, 4×
and 8×.
Note
When switching the digital zoom ratio, the left interface displays the actual
magnification (Actual Magnification = Lens Optical Magnification × Digital
Zoom Ratio). For example, the lens optical magnification is 1.8× and the
digital zoom ratio is 2×, and the actual magnification is 3.6×.
3.12
Flat Field Correction
This function can correct non-uniformity of display.
Steps
1. Hold to show the menu.
2. Go to Advanced Settings, and select Function Settings.
3. Press or to select , and press to enter the
configuration interface.
4. Press or to switch FFC mode.
