HIKVISION DS-1600KI User Manual

22
3) Select the security type as shown in Figure 3.9.
Figure 3.9 Selecting the Security Type
4) Enter the password to connect to the network.
If you open both the Ethernet and WLAN, the WLAN takes effect by default.
3.3 Language Settings
Purpose:
You can choose language for the device in this section.
Steps:
1. Click the Language button on the right of the General interface to enter the Language Configuration
interface.
2. Click the radio button to to select the Chinese or English language.
Figure 3.10 Language Configuration Interface
3.4 Date and Time Settings
Purpose:
You can set date and time and select time zone by configuring the parameters.

HIKVISION DS-1600KI Specifications

General

Purpose	Universal
USB hub	Yes
Pointing device	No
Device interface	USB
Recommended usage	Service
Keyboard key switch	-
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	LCD
Product color	Black
Keyboard style	Straight
Form factor	Right-hand
Operating voltage	12 V
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Keyboard weight	1700 g
Keyboard dimensions (WxDxH)	404 x 180 x 163 mm
