HIKVISION DS-1600KI User Manual

86
7.1 Specifications
7.2 Summary of Changes
Version 1.1.0
Added:
1. Accessible by iVMS platform and matrix access gateway.
2. Configurable by SADP;
3. Double-click to realize full-screen live view and then double-click to restore to the normal live view mode;
4. Control the front panel of the added DVR/NVR in device management;
5. Optimize the PTZ control via the joystick and support 3D PTZ control;
6. Up to 4 patterns can be configured;
7. Connectable to multiple models of decoders and multi-screen controllers;
Model
DS-1600KI
Operating System
Android 4.4
TFT LCD Screen
10.1" TFT LCD touchscreen
Resolution: 1024 × 600
Joystick
4-axis joystick
Local Decoding
Local decoding 2-ch at up to 1080p resolution , and up to 16-division window display
Two-way Audio
Input
1-ch, 3.5 mm connector
(2.0Vp-p, >10kΩ)
Audio Output
1-ch, 3.5 mm connector (2.0 Vp-p, 600 Ω)
Network Interface
1 10M/100M/1000M self-adaptive Ethernet interface
WiFi
Supported
USB Interface
USB 2.0 × 2
Video Interface
1 HDMI, 1 DVI
Power Supply
12 VDC/POE
Consumption
≤ 15W
Working
Temperature
-10°C to ＋55°C (14ºF to 131ºF)
Working Humidity
10％ to 90％
Dimensions
(W × D × H)
404 × 180 × 163 mm (15.9 × 7.1 × 6.4 inch)
Weight
1.7 Kg

HIKVISION DS-1600KI Specifications

General

Purpose	Universal
USB hub	Yes
Pointing device	No
Device interface	USB
Recommended usage	Service
Keyboard key switch	-
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	LCD
Product color	Black
Keyboard style	Straight
Form factor	Right-hand
Operating voltage	12 V
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Keyboard weight	1700 g
Keyboard dimensions (WxDxH)	404 x 180 x 163 mm
