HIKVISION DS-1600KI User Manual

74
Figure 5.2 Main Menu of Platform Configuration
Refer to Table 5.1 for the description of the main menu.
Table 5.1 Description of Main Menu
Menu
Description
Video Wall
Display the live video of the input channel on the output monitor of the video wall.
Resource
Display the resource list.
Logout
Log out of the platform module.
5.1.3 Managing the Video Wall
After logging in to the platform, you should select the video wall first. Click on the main menu to enter
the Resource List interface. The resource list contains the resources configured in iVMS 5200platform.

HIKVISION DS-1600KI Specifications

General

Purpose	Universal
USB hub	Yes
Pointing device	No
Device interface	USB
Recommended usage	Service
Keyboard key switch	-
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	LCD
Product color	Black
Keyboard style	Straight
Form factor	Right-hand
Operating voltage	12 V
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Keyboard weight	1700 g
Keyboard dimensions (WxDxH)	404 x 180 x 163 mm
