Purpose:
You can get access to the matrix access gateway, realize unified management of the monitors, switch the live video
on the video wall and set PTZ control on the Matrix module.
The PTZ control should be supported by the added device.
6.1 Matrix Access Gateway Login
Click on the home page to enter the Matrix Access Gateway Login interface.
Figure 6.1 Matrix Access Gateway Login Interface
Steps:
1. Enter the IP address, Port, User Name and Password of the matrix.
2. (Optional) Select the checkbox of Remember Password if you want to save the password.
3. Click Login.
6.2 Configuring the Video Wall
After login, you can enter the Video Wall interface.
There is a numeric panel on the right with numbers 0 to 9 and five other icons for you to enter the number of the
device.
Figure 6.2 Video Wall Numeric Panel

HIKVISION DS-1600KI Specifications

General

Purpose	Universal
USB hub	Yes
Pointing device	No
Device interface	USB
Recommended usage	Service
Keyboard key switch	-
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	LCD
Product color	Black
Keyboard style	Straight
Form factor	Right-hand
Operating voltage	12 V
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Keyboard weight	1700 g
Keyboard dimensions (WxDxH)	404 x 180 x 163 mm
