HIKVISION DS-2DE2A204IW-DE3 User Manual

Chapter 4 Live View
It introduces the live view parameters, funcon icons and transmission parameters sengs.
4.1 Live View Parameters
The supported funcons vary depending on the model.
4.1.1 Start and Stop Live View
Click
Live View. Click
to start live view. Click to stop live view.
4.1.2 Aspect
Rao
Aspect Rao is the display rao of the width to height of the image.
●
refers to 4:3 window size.
●
refers to 16:9 window size.
●
refers to original window size.
●
refers to self-adapve window size.
4.1.3 Live View Stream Type
Select the live view stream type according to your needs. For the detailed informaon about the
stream type selecon, refer to Stream Type .
4.1.4 Quick Set Live View
It oers the quick access to the display sengs, OSD, and video/audio on live view page.
Steps
1.
Click and click General to show quick setup page.
2.
Set display sengs, OSD, and video/audio.
-
For parameter explanaon and instrucons of display sengs, see Display Sengs .
-
For parameter
explanaon and instrucons of OSD sengs, see OSD .
-
For parameter
explanaon and instrucons of audio and video sengs, see Video and Audio .
Network Speed Dome User Manual
18

HIKVISION DS-2DE2A204IW-DE3 Specifications

General

Sensor type	CMOS
Progressive scan	Yes
Number of sensors	1
Optical sensor size	1/3 \
Maximum resolution	1920 x 1080 pixels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Pan range	0 - 330 °
Pan speed	100 °/sec
White balance	ATW, Auto, Manual
Tilt angle range	0 - 90 °
Camera shutter speed	1/1 - 1/30000 s
Minimum illumination	0.005 lx
Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Focus	Motorized/Manual
Digital zoom	16 x
Optical zoom	4 x
Focal length range	- mm
Maximum aperture number	2.7
Minimum aperture number	1.6
Detection distance	0.01 m
Audio input channels	1 channels
Wi-Fi	-
Number of users	20 user(s)
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1x
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, SDXC
DC output voltage	12
Power source type	DC
Power consumption (typical)	12 W
Operating temperature (T-T)	-20 - 60 °C
IK code	IK10
Form factor	Dome
Product color	Black, White
Housing material	Acrylonitrile butadiene styrene (ABS), Aluminium, Polycarbonate (PC)
International Protection (IP) code	IP66

Weight and Dimensions

Width	130.7 mm
Height	101.7 mm
Weight (with stand)	530 g
