Figure 7-6 Draw Area
8.
Click Save.
9.
Repeat above steps to set other regions.
10.
Set arming schedule. See
Set Arming Schedule .
11.
Set linkage method. See Linkage Method Sengs .
7.2.6 Set Region
Exing Detecon
Region exing detecon is used to detect the objects movement of exing from a predened area.
When it occurs, the device takes linkage acons as response.
Steps
1.
Go to Conguraon → Event → Smart Event → Region Exing Detecon .
2.
Check Enable.
3.
Oponal: Click Lock to lock PTZ control to prevent the interrupon from other PTZ related acon
during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
4.
Adjust the live image to the desired scene by using PTZ control
buons.
5.
Draw detecon area.
1) Select a Region No.. Up to 4 regions can be set.
2) Click
Detecon Area.
3) Click on the live image to draw the boundaries of the
detecon area, and right click to
complete drawing.
Network Speed Dome User Manual
54

HIKVISION DS-2DE2A204IW-DE3 Specifications

General

Sensor type	CMOS
Progressive scan	Yes
Number of sensors	1
Optical sensor size	1/3 \
Maximum resolution	1920 x 1080 pixels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Pan range	0 - 330 °
Pan speed	100 °/sec
White balance	ATW, Auto, Manual
Tilt angle range	0 - 90 °
Camera shutter speed	1/1 - 1/30000 s
Minimum illumination	0.005 lx
Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Focus	Motorized/Manual
Digital zoom	16 x
Optical zoom	4 x
Focal length range	- mm
Maximum aperture number	2.7
Minimum aperture number	1.6
Detection distance	0.01 m
Audio input channels	1 channels
Wi-Fi	-
Number of users	20 user(s)
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1x
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, SDXC
DC output voltage	12
Power source type	DC
Power consumption (typical)	12 W
Operating temperature (T-T)	-20 - 60 °C
IK code	IK10
Form factor	Dome
Product color	Black, White
Housing material	Acrylonitrile butadiene styrene (ABS), Aluminium, Polycarbonate (PC)
International Protection (IP) code	IP66

Weight and Dimensions

Width	130.7 mm
Height	101.7 mm
Weight (with stand)	530 g
