User Manual of DS-7100HWI/HVI-SL Series DVR
22
3.2 Operations in Live View Mode
In live view mode, the following functions can be realized:
• Single Screen: showing only one screen on the monitor.
• Multi-screen: showing multiple screens on the monitor simultaneously.
• Auto-switch: the screen is auto switched to the next one. And you must set the dwell time for each
screen on the configuration menu before enabling the auto-switch.
Menu>Configuration>Live View>Dwell Time.
• All-day Playback: play back the recorded videos for current day.
• Start Recording: start all-day normal recording or motion detection recording for all channels.
• Aux/Main Monitor switch: the DVR will check the connection of the output interfaces to define the
main and auxiliary output interfaces. When both VGA and CVBS are connected, the DVR detects the
VGA as the main video output (live view, playback and men operations) and the CVBS as the auxiliary
video output (live view and recording).
When the aux output is enabled, you can do some basic operation on the live view mode for the Aux output,
while no operation is allowed for the main output.
3.2.1 Using the Mouse in Live View
In the live view mode, use the mouse to right-click on the window to access the following menu:
Figure 3.1 Right-click Menu
Table 3.2 Mouse Operation in Live View
Enter the main menu of the system by right-clicking the mouse.
Switch to the single full screen by choosing channel number from the dropdown list.
Adjust the screen layout by choosing from the dropdown list.
Switch to the previous screen.
Switch to the next screen.
Enable/disable the auto-switch of the screens.
