HIKVISION DS-7116HGHI-F1 User Manual

Digital Video Recorder User Manual
316
Model
DS-8104HQHI-F8/N
DS-8108HQHI-F8/N
DS-8116HQHI-F8/N
USB
interface
Front panel: 2 × USB 2.0
Rear panel: 1 × USB 3.0
Serial
interface
RS-232, RS-485 (full-duplex), Keyboard
Alarm in/out
16/4
General
Power
supply
100 to 240 VAC
Consumption
(without
HDD)
≤ 30 W
≤ 40 W
≤ 55 W
Working
temperature
-10 ºC to +55 ºC (14 ºF to 131 ºF)
Working
humidity
10% to 90%
Dimensions
(W × D × H)
445 × 470 × 90 mm (17.5 × 18.5 × 3.5 inch)
Weight
(without
HDD)
≤ 8 kg (17.6 lb)
18.2 Glossary
• Dual-Stream: Dual-stream is a technology used to record high resolution video locally while
transmitting a lower resolution stream over the network. The two streams are generated by
the DVR, with the main stream having a maximum resolution of 1080P and the sub-stream
having a maximum resolution of CIF.
• DVR: Acronym for Digital Video Recorder. A DVR is device that is able to accept video signals
from analog cameras, compress the signal and store it on its hard drives.
• HDD: Acronym for Hard Disk Drive. A storage medium which stores digitally encoded data on
platters with magnetic surfaces.
• DHCP: Dynamic Host Configuration Protocol (DHCP) is a network application protocol used
by devices (DHCP clients) to obtain configuration information for operation in an Internet
Protocol network.

HIKVISION DS-7116HGHI-F1 Specifications

General

Bit rate	64 Kbit/s
Certification	CE
Product color	White
Channels quantity	16 channels
Maximum frame rate	30 fps
Audio output channels	2.0 channels
Audio formats supported	G.711 μ-law
Multi-display supported	Yes
Network connection type	RJ-45
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264, H.264+
Playback resolutions supported	1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Audio input	1x RCA
BNC input ports	16
USB 2.0 ports quantity	2
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
DC voltage	12 V
Power supply type	DC
Power consumption (typical)	20 W

Weight and Dimensions

Depth	210 mm
Width	285 mm
Height	45 mm
Weight	1200 g
