User Manual of Digital Video Recorder
129
8.6 Handling Exceptions
Purpose:
Exception settings refer to the handling method of various exceptions, e.g.
• HDD Full: The HDD is full.
• HDD Error: Writing HDD error, unformatted HDD, etc.
• Network Disconnected: Disconnected network cable.
• IP Conflicted: Duplicated IP address.
• Illegal Login: Incorrect user ID or password.
• Input/Recording Resolution Mismatch: The input resolution is smaller than the recording resolution.
• Record Exception: No space for saving recorded files.
Steps:
1. Enter Exceptions interface and handle various exceptions.
Menu> Configuration> Exceptions
DS-7100HGHI-SH and DS-7200HGHI-SH
Other Models
Figure 8. 16 Exception Settings Interface
2. Check the checkbox of Enable Event Hint to display the (Event/Exception icon) when an
exceptional event occurs. And click the icon to select the detailed event hint for display.
Click the icon appears in the live view interface, and you can view the detailed information of
the exceptional event. Click the button Set, and then you can select the detailed event hint for
display.

HIKVISION DS-7204HGHI-SH Specifications

General

Product color	Black
Channels quantity	4 channels
Total storage capacity	1000 GB
Video compression formats	H.264
Playback resolutions supported	1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Audio input	1
BNC input ports	4
USB 2.0 ports quantity	2
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Power requirements	12V DC
Power consumption (typical)	15 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Dimensions (WxDxH)	315 x 242 x 45 mm
