User Manual of Digital Video Recorder
129
Figure 9. 11 Access Device via iVMS4200
5. Click the Apply button to save and exit the interface.
9.2.3 Configuring NTP Server
Purpose:
A Network Time Protocol (NTP) Server can be configured on your DVR to ensure the accuracy of system
date/time.
Steps:
1. Enter the Network Settings interface.
Menu > Configuration > Network
2. Select the NTP tab to enter the NTP Settings interface.
Figure 9. 12 NTP Settings Interface
3. Check the Enable NTP checkbox to enable this feature.
4. Configure the following NTP settings:
• Interval: Time interval between the two synchronizing actions with NTP server. The unit is minute.
• NTP Server: IP address of NTP server.
• NTP Port: Port of NTP server.
5. Click the Apply button to save and exit the interface.
The time synchronization interval can be set from 1 to 10080 minutes, and the default value is 60
minutes. If the DVR is connected to a public network, you should use a NTP server that has a time
synchronization function, such as the server at the National Time Center (IP Address: 210.72.145.44). If
the DVR is set in a more customized network, NTP software can be used to establish a NTP server used
for time synchronization.
