User Manual of Digital Video Recorder
160
12.1 Viewing System Information
12.1.1 Viewing Device Information
Steps:
1. Enter the System Information interface.
Menu > Maintenance > System Info
2. Click the Device Info tab to enter the Device Information menu to view the device name, model, serial No. ,
firmware version and encoding version, as shown in Figure 12. 1.
Figure 12. 1 Device Information Interface
12.1.2 Viewing Camera Information
Steps:
1. Enter the System Information interface.
Menu > Maintenance > System Info
2. Click the Camera tab to enter the Camera Information menu to view the status of each camera, as shown in
Figure 12. 2.
Figure 12. 2 Camera Information Interface
12.1.3 Viewing Record Information
Steps:
1. Enter the System Information interface.
Menu > Maintenance > System Info
2. Click the Record tab to enter the Record Information menu to view the recording status encoding parameters
of each camera, as shown in Figure 12. 3.
